Overview
The Military Refueler is based on the proven MAN TGS 33.400 6×6 BB CH truck — a robust, purpose-built, heavy-duty chassis from the current TGS generation. Designed as a platform truck and chassis (LK), it is supplied without a body. The addition of the 12,000-liter capacity refined-fuels storage tank and pump system provides a certified safe fuel delivery system for combat vehicles in the field.
Specifications
| Gross Vehicle Weight | 33,000 kg |
|---|---|
| Front Axle | 7,500 kg |
| Rear Axle 1 | 13,000 kg |
| Rear Axle 2 | 13,000 kg |
| Total Length | 9,320 mm |
| Wheelbase (main) | 3,900 mm |
| Wheelbase (rear axles) | 1,400 mm |
| Front Overhang | 1,605 mm |
| Rear Frame Overhang | 2,050 mm |
| Frame Height (unladen) | 1,238 mm |
| Frame Height (laden) | 1,135 mm |
| Width over Cab | 2,240 mm |
| Width incl. Mirrors | 2,981 mm |
| Frame Profile | 270 × 85 × 9.5 mm |
| Frame Width (front / rear) | 945 / 765 mm |
| Turning Circle (track) | 18.8 m |
| Wall-to-wall Turning Circle | 20.5 m |
| Parent Product # | VE-TW-C-0858 |
